S251 Industrial Grade MSATA SSD 256GB 512GB 1tb Mini Sata Ssd

Name: S251 Industrial Grade MSATA SSD 256GB 512GB 1tb Mini Sata Ssd
Brand: Shenzhen Quadra Seven Technology Co., Ltd.
SKU: S251
Price: 260.00 USD
Availability: InStock

Brand Name:	NUW
Model Number:	S251
MOQ:	10
Price:	$70-450/pcs
Delivery Time:	10-15days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

AEC-Q100、RoHS、REACH、UL/CE

Form Factor:

MSATA

Interface:

SATA Ⅲ(SATA Ⅱ& SATA Ⅰ COMPATIBLE)

Operating Temperature:

-40℃ ~ 85℃

Dimension(mm):

50.95×30.0×3.8

Packaging Details:

Customizable Packaging Available

Supply Ability:

100k/month

Highlight:

Industrial Grade mSATA SSD

msata ssd 1tb

512GB mini sata ssd

Product Description

Product Description

NUW S251 series industrial mSATA SSD Module combines compact size (50x30mm) with SATA III 6Gb/s speeds (up to 560/520MB/s), engineered for harsh environments with -40°C to 85°C wide-temperature tolerance and anti-vibration/anti-shock design. Built with industrial-grade 3D TLC NAND and features like LDPC ECC, power-loss protection (PLP), and conformal coating, it ensures data integrity and longevity in mission-critical applications. Ideal for industrial automation, transportation systems, medical devices, and embedded edge computing, this module offers 32GB–2TB capacities to balance rugged reliability with cost-efficiency.

Product Parameters

Basic Information
Form Factor	mSATA
Interface	SATA Ⅲ(SATA Ⅱ& SATA Ⅰ COMPATIBLE)
Dimension(mm)	50.95×30.0×3.8
Cache	DRAM-Less
Flash	TLC
Capacity	pSLC:32GB, 64GB, 128GB, 256GB, 512GB TLC:128GB, 256GB, 512GB, 1TB, 2TB
Temperature
Operating Temperature	-40℃ ~ 85℃
Storage Temperature	-55℃ ~ 95℃
Performance
Sequential Read/Write	560MB/s; 520MB/s
Random Read/Write(4K) IOPS	98K IOPS; 30K IOPS
Reliability
MTBF	2,000,000hrs
Vibration	15g(10~2000Hz)
Shock	1500g/0.5ms
Humidity	5% ~ 95% (No condensing)
Electrical
Power Supply	3.3V±5%
Power Consumption	Active≤3.2W Idle≤0.7W
Optional Functions
Secure Erase	Y
Quick Erase	Y
